Cast Polyurethane Rubber Sheet

Custom Cast Polyurethane Rubber Sheets



- Custom cast urethane sheets manufactured to your dimensions, hardness and performance requirements.



- Broad hardness, thickness and color options for wear liners, pads, seals, spacers and machined parts.



- Formulations available for abrasion, oil, hydrolysis, UV, antistatic and flame-retardant requirements.



- Cutting, drilling and milling services help reduce downstream processing.



- Little or no tooling cost for many standard sheet sizes.



INDUSTRIES SERVED: Mining, Automotive, Industrial Equipment, Electronics, Food Processing and Chemical Processing





Inquire Now WhatsApp Now

We are a China-based manufacturer of custom cast polyurethane rubber sheets, also known as urethane sheeting or PU rubber sheet. We use quality raw materials, including BASF systems where specified, and tailor hardness, dimensions and formulation to applications that face frequent wear, impact or maintenance.

Polyurethane sheets can be cut or machined into rings, gaskets, rollers, wheels, squeegees and other components. Typical uses include wear-resistant machinery linings, automotive seals and vibration-damping pads, construction formwork liners and impact pads. Food-contact applications require a formulation and compliance documentation selected for the intended use.

Customization Options:

Customization ItemsSpecificationsIndustry-Specific Cases
Basic SpecificationThickness: 2-200 mm; common options include 2, 3, 5, 6, 8 and 10 mm

Maximum width and length: 4,000 x 2,000 mm

Hardness: Shore 5A-98A and up to 80D

Density: 1.1-1.25 g/cm³

Color: Black, white, natural, 30+ stocked colors and custom color matching		Thickness 2-5 mm: Electronic-device buffer gaskets

Irregular sizes: Non-standard machinery installation spaces

Higher-density grades: Heavy-equipment load-bearing parts
Custom Performance & PropertiesOutdoor service: UV-stabilized formulations available

Conductive/antistatic: Surface resistance options from 10³ to 10¹¹ Ω
High resilience: Rebound targets available by formulation		UV-stabilized: Outdoor PV-equipment seals

Antistatic: Workbenches in electronic component workshops

High elasticity: Shock absorbers/buffer pads
Material CompositePU + rubber composite; low-temperature grades available to -40°C

PU + fabric lamination for higher tear resistance

PU + metal-backed urethane sheet		Low-temperature composite: Cold chain equipment sealing gaskets

Fabric lamination: Conveyor belt surface layers

Metal-backed composite: Heavy-machinery support pads
Appearance & ProcessSurface texture: Diamond or striped anti-slip patterns

Printed marks: Custom logos/size scales

Edge processing: Precision cutting and die-cutting; tolerances confirmed by drawing		Anti-slip texture: Workshop foot pedals/logistics pallets

Printed marks: Identification for equipment-specific gaskets

Laser precision cutting: Precision instrument assemblies
Industry ComplianceMarine grade: Formulations for seawater exposure; testing available by specification

Mining grade: Flame-retardant formulations available to specified test requirements
FDA- and RoHS-compliant materials available on request		Marine grade: Marine pipeline seals

Mining: Conveyor-belt scrapers
Food processing: Liners and seals

Applications of Polyurethane Rubber Sheets

– Mining & Quarrying: Chute and hopper liners, conveyor-belt scrapers, wipers, wear plates, sliding strips and screens.

– Automotive: Bushings, shock absorbers, seals, gaskets, suspension components and vibration-damping pads.

– Construction & Infrastructure:

Expansion joints, load-bearing pads, impact-resistant panels, and structural components.

– General Manufacturing & Material Handling:

Sliding strips, cutting sticks, industrial liners, protective pads, conveyor components, dampers, buffers, bumpers, wheels and rollers.

– Food & Pharmaceutical Processing:

Equipment liners, seals and wear pads using materials selected for the required hygiene and compliance standard.

– Metal Forming:

Die pads, press-brake tooling and protective pads for forming processes.

custom-urethane-sheets

Advantages of Polyurethane Rubber Sheets

– High abrasion resistance: Properly formulated polyurethane can provide longer wear life than many conventional elastomers in sliding and impact applications. Actual results depend on formulation and operating conditions.

– Outdoor formulations: UV-stabilized grades are available for sunlight and weather exposure. Standard polyurethane should be evaluated before prolonged outdoor use.

– Low-temperature performance: Selected formulations can retain flexibility at temperatures down to about -40°C. Confirm the service range for the specified grade.

– Impact and vibration damping: Elastic polyurethane helps absorb shock and vibration in pads, bumpers and mounts.

– Machinability: Sheets can be cut, drilled or milled to custom shapes and dimensions, depending on hardness and thickness.

Why Choose Our Polyurethane Rubber Sheets?

– Material systems selected to balance performance and cost.

– Hardness options from Shore 5A to 80D; 70A, 80A and 90A are common.

– Sheet sizes up to 1 x 4 m or 1.5 x 3 m, depending on hardness and thickness.

– Polyester, polyether and specialty systems based on TDI, MDI, NDI, HDI, PPDI, PCL or PCD chemistry.

– More than 30 stocked colors, plus custom color matching.

– Optional antistatic, flame-retardant, hydrolysis-resistant, mildew-resistant, UV-stabilized and enhanced-wear formulations.

– Many standard sheet sizes require little or no tooling.

– Cutting, drilling and milling services are available.

– Multiple casting tables and centrifugal equipment support short lead times.

– D44-grade and high-performance NDI-based polyurethane sheets are available.

– Sheets can be cast or molded when tighter tolerances are required.

anti-static polyurethane sheet

  • Are you a manufacturer?

    Yes. We are manufacturer. Welcome to visit our factory.

  • Can you introduce your customized process ?

    Yes. The process includes Share needs → design & quote → prototype (opt) → production → delivery.

  • How do you control your product quality?

    We have 10 inspectors to carry out raw material inspection, process control ,first article inspection and final inspection.

  • How do you monitor the production process to avoid delayed delivery?

    We use the ERP system to execute orders, and can check the order status and expected delivery time at any time.

  • What is warranty of products?

    All of products with 3-6 months guarantee (except very frequently wearing parts).

  • How do you deal with after sales service?

    We will response in 24 hours with solutions such as replacement or reworking.

  • How do you deal with customers' molds?

    We have dedicated personnel to sort out and maintain molds regularly.

  • What about the lifespan of molds?

    20,000 times for compressions molds and 30,000 time for casting molds

  • How long can you keep customers' molds for free?

    Due to the large quantity of molds, we can keep the molds for free for 2 to 3 years even if no order.

  • If the molds are damaged or reach the lifespan , who will be responsible for it ?

    Customers only need to pay mold cost once. We will cover the cost if molds are damaged or reach the lifespan.
